Electronic System
Drive Unit: Bosch Performance Line, Smart System, (20 mph)
Battery: Bosch PowerTube, 500Wh
Charger: Bosch 4A
Display: Bosch Intuvia w/ LED remote
Extras:
- Integrated headtube running light
- Axa Compactline 35E front light
- Axa Blueline rear light
- Abus framelock (key-matched with battery lock)
- Tubus rear rack (25kg, Racktime compatible)
- Full-coverage fenders
Power: Bosch's new Smart System Performance drive unit and 500Wh battery provide effortless power.
Speed: This e-bike drive system provides pedal assist up to a maximum speed of 20mph. Above that, it’s all you.
Range: Up to 70mi of assisted range mean you can go to – and come back from – just about anywhere.
Frameset
Frame: SmartForm C2 Alloy, step-thru, removable 500Wh downtube battery, integrated front running light, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection
Fork: SR Suntour Mobie A32, 63mm travel, coil with preload adjuster, lockout, crown light mount, 44mm offset
Headset: Semi-Integrated, Tapered; 1-1/8"-1-1/2"
Drivetrain
Rear Derailleur: microSHIFT Marvo, 9-speed
Shifters: microSHIFT Marvo XPress M859, trigger style, 9-speed
Chain: KMC X9, 9-speed
Crank: FSA for Bosch
Rear Cogs: microSHIFT H-Series, 11-36, 9-speed
Brakes
Brakes: Shimano MT400 hydraulic disc, 180/180mm RT30 rotors
Brake Levers: Shimano MT400 hydraulic disc
Wheels
Rims: Alloy, double wall, 32 hole, 25mm internal width, disc-specific
Spokes: Stainless steel, 14g
Hubs: (F) Shimano MT400B, 110x15mm thru-axle / (R) Shimano UR600, 135QR
Front Tire: Continental Race King, 27.5x2.20" 55-584
Rear Tire: Continental Race King, 27.5x2.20" 55-584
Components
Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 740mm
Stem: Cannondale 3 with Intellimount, Alloy, 31.8mm clamp
Grips: Cannondale Ergo Fitness Dual Density, Lock-on
Saddle:
Selle Royal Vivo Active Ergo with reflective accents
Seatpost:
Cannondale 4, 6061 Alloy, 31.6
