Frame
Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disc brake, kickstand mount, 144.5mm OLD hub motor spacing
-
Fork
Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm bolt-on skewer
-
Hub front
Alloy low-flange w/6-bolt disc, 36h, w/QR
-
Skewer front
132x5mm QR, ThruSkew
-
Rim
Alloy double wall, 36h
-
Tire
Bontrager GR0 Comp, wire bead, 60 tpi, 650x50mm
-
Max tire size
650x50mm
-
Battery
520Wh, integrated in down tube
-
Charger
Trek Easy Mag charger, 2.7A, 54.9V output, 100V-240V AC input
-
Computer
LCD display
-
Motor
Hub drive motor, 60 Nm, 500W, 36H, black
-
E-bike Classification
Class 2
-
Shifter
Shimano M315, 8 speed
-
Rear derailleur
Shimano ESSA U2000
-
Crank
Alloy, 40T steel chainring, 170mm length
-
Cassette
Shimano HG400, 11-45, 8 speed
-
Chain
KMC Z8.3
-
Pedal
Bontrager City pedals
-
Max chainring size
1x: 40T
-
Saddle
Bontrager Sport
-
Seatpost
Size: S, M: Bontrager alloy, 31.6mm, 12mm offset, 330mm length; Size: L, XL: Bontrager alloy, 31.6mm, 12mm offset, 400mm length
-
Handlebar
Size: S, M: Bontrager alloy, 31.8mm, 15mm rise, 690mm width; Size: L, XL: Bontrager alloy, 31.8mm, 15mm rise, 720mm width
-
Grips
Bontrager XR Endurance Comp, lock-on
-
Stem
Size: S, M: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: L, XL: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
-
Brake
Rush BH-286 hydraulic disc, 180mm rotor
-
Rotor size
Max brake rotor sizes: 180mm front & rear
-
Light
Size: S, M, L, XL: Herrmans MR8, 180 lumen, 60 lux, LED headlight; Size: S, M, L, XL: Sate-Lite M-15 with turn signal and brake light function
-
Kickstand
Adjustable length alloy kickstand
-
Weight
M - 22.10 kg / 48.73 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
